Product Name: 70x7mm Model CNC Pipe Clamp Bending Machine
Model: 70x7mm Model Pro Max
Dimensions: 2850x1800x1550mm
Weight: 2000kg
Total Power: 34.5kW
Operating Voltage: 3-Phase 380V
Processing Materials: Carbon steel, galvanized strip, stainless steel
Processing Width: 10–70mm
Processing Thickness: 2–7mm
Processing Diameter: 150–600mm
Language: Chinese/English
Operation Mode: CNC
Max. Feeding Speed: 65m/min
Max. Bending Speed: 960°/sec
Operating Environment: Temperature -10°C to 30°C
Key Selling Points: High precision, CNC control
Warranty: 1-year warranty, lifetime maintenance
Inspection Methods: Video inspection, sample inspection
Core Functions: Bending, cutting, punching, custom logo, feeding, leveling
Place of Origin: Botou City, Cangzhou City, Hebei Province
Brand Name: Hongjicheng
Shape Tolerance: ±0.2mm
Certificates: CE
Applications: Pipe clamp bending, pipe bracket bending
Supports remote network operation; convenient system upgrades and maintenance
Core Components: PLC system, touch screen, hydraulic cylinder, hydraulic system, servo motor, planetary gearbox
